Aspen Mini Blanc Gen 4.5 Condensate Pump (FP3578)
The Aspen Mini Blanc Gen 4.5 is a compact, white mini condensate pump for high wall split air conditioning and air-to-air heat pump indoor units up to 26kW (90,000 Btu/h). It fits neatly beside or below the indoor unit and lifts condensate to a suitable drain where gravity drainage isn't possible.
- Maximum flow 20 L/h at 0m head, maximum recommended head 10m (4 L/h at 10m)
- Quiet operation: 19 dB(A) at 1m
- Removable reservoir for easy maintenance and cleaning
- Self-priming, continuous rated
- 5A normally closed safety switch to stop the indoor unit if the pump can't keep up
- 100-250V AC 50/60Hz, 5W, Class II, IP24
- 24 month manufacturer's warranty
What's included
- Mini Blanc pump
- 1.5m hardwired power cable
- Fitting templates
- Quick start guide
Specification and price
| Part number | Aspen FP3578 |
|---|---|
| Application | High wall split units |
| Maximum unit output | 26kW / 90,000 Btu/h |
| Maximum flow | 20 L/h at 0m head |
| Maximum recommended head | 10m (4 L/h) |
| Noise | 19 dB(A) at 1m |
| Power supply | 100-250V AC, 50/60Hz, 5W, 0.16A |
| Safety switch | 5A normally closed |
| Inlet / outlet | 20mm inlet, 6mm outlet |
| Max water temperature | 40°C |
| IP rating | IP24 |
| Dimensions | 290 x 50 x 65mm |
| Weight | 0.48kg |
| EAN | 5060926521596 |
| Warranty | 24 months |
| Price | £169.99 inc VAT |
Options
For a pump hidden inside trunking, see the Aspen Silent+ Mini Lime trunking kit in our condensate pump range.
Installation and compliance
Install to Aspen's instructions and the indoor unit manufacturer's requirements. The pump is hardwired and needs a permanent mains supply, so the electrical connection (including the safety switch) should be made by a competent person in line with BS 7671. Run the discharge to a suitable drain.
Delivery and collection
Free UK delivery on orders over £50, £4.99 on orders under £50. Free collection from our Lincoln unit, usually ready within 24 hours.
Manufacturer datasheet is in the PDF downloads at the bottom of this page.
PDF Downloads
Manufacturer documents for this product.
