EPH Controls V228P 28mm 2 Port Motorised Valve
The EPH V228P is a 28mm compression 2 port motorised zone valve for zoning heating and hot water circuits on domestic wet systems. It is powered open and spring returns to closed, and the actuator and cable detach from the valve body so the head can be changed without draining the system.
Key points
- 28mm compression connections
- Flow rate Kvs 6.8 m³/h
- Maximum close-off pressure 0.6 bar
- 230V motor, 5W power consumption
- Detachable actuator and 1.2m pre-wired cable
- Auxiliary switch (N/O, COM and N/C) rated 11(3)A 230V
- Power-on indicator light
What's included
- 1 x EPH V228P 28mm 2 port valve body with detachable actuator and 1.2m cable
Specification
| Model | V228P |
| Connection | 28mm compression |
| Kvs | 6.8 m³/h |
| Max close-off pressure | 0.6 bar |
| Max static / operating pressure | 21 bar |
| Fluid temperature | 2 to 88°C |
| Max ambient (actuator) | 50°C |
| Supply | 230V, 5W |
| Auxiliary contact rating | 11(3)A 230V |
| Cable | 1.2m (brown, blue, grey, orange, white, green/yellow) |
| Protection | IP20 |
| Operation | Powered open, spring return to closed |
| Price | £79.99 inc VAT |
Options
For 22mm pipework, use the EPH V222P 22mm 2 port zone valve.
Installation and compliance
Must be installed by a competent person in line with current wiring regulations, with an earth connection and a fuse of no more than 3A. Do not insulate or cover the actuator. EPH states these valves are for domestic applications only; fitting in any other application voids the warranty. Check the system's differential pressure is within the 0.6 bar close-off rating.
Delivery and collection
Free UK delivery on orders over £50, or £4.99 under £50. Free collection from our Lincoln unit, usually ready within 24 hours.
Manufacturer datasheet is in the PDF downloads at the bottom of this page.
PDF Downloads
Manufacturer documents for this product.
