Inaba Denko Slimduct 45° Vertical Elbow

A genuine Inaba Denko Slimduct 45° vertical elbow (SCF series) for taking Slimduct line set trunking through a 45° bend away from or towards the wall, for example to step a run out around a soffit, plinth or other obstruction, when running refrigerant pipework, condensate and interconnecting cable between an air conditioning or heat pump indoor and outdoor unit. Stocked in 75mm (white, black and anthracite) and 100mm (black).

Key points

• 45° vertical bend for Inaba Slimduct trunking
• 75mm (SCF-77) and 100mm (SCF-100) sizes to match Slimduct straight duct
• Colours in stock: 75mm white, black and anthracite; 100mm black
• 75mm size suits pipe pairs up to 3/8" and 5/8" with 13mm insulation
• Fire-retardant, UV-resistant PVC, suitable for indoor and outdoor use
• Gives a neat, professional finish to exposed AC and heat pump pipe runs

What's included

• 1 × Inaba Denko Slimduct 45° vertical elbow in the size and colour selected

Sizes, colours and prices

Options

Choose the size to match your Slimduct straight duct (75mm or 100mm) and the colour to match the rest of the run. Fittings from different Slimduct sizes are not interchangeable without a reducer. For a 45° bend across the wall face rather than away from it, use a flat elbow.

Installation & compliance

For use with Inaba Denko Slimduct trunking only. Fix the duct base to the wall, lay the pipework and cable, then clip the cover in place. Refrigerant pipework inside the trunking must be installed and tested by a suitably qualified F-Gas certified engineer; the trunking itself does not need F-Gas certification to buy.

Delivery & collection

Free UK delivery on orders over £50, £4.99 under £50. Free collection from our Lincoln unit (Leafbridge Business Park, LN6 9WG), usually ready within 24 hours.
